Exercise bike and spin bike dimensions

Listed footprints of bikes in our guides

The table below uses the length (D), width (W) and height (H) shown on each product listing for bikes that appear in our buying guides. They are the sellers' figures, rounded to the nearest centimetre. Where the numbers look plausible for an assembled bike, they are included here. Measurements can change between versions, so confirm the figures in the manual or with the seller before you commit to a space.

Use the table to get a feel for each type. Folding X-bikes are short, uprights are compact, spin bikes are a little longer, and recumbents need the most floor because the seat sits behind the pedals.

Listings that look wrong and should be checked

Several listings give numbers that cannot be an assembled bike. Some show a width under 20 cm, which is far too narrow for a bike with pedals and a base, and is more likely the shipping box. Others seem to have length, width and height in the wrong order, for example a width above a metre with a height near 50 cm. One recumbent listing gives a footprint smaller than many folding bikes. A few listings also show user weight or height limits that do not make sense alongside the bike.

If you are buying one of these, ask the seller for the assembled size, or find the manual on the maker's website, before you measure up. Do not plan a tight space around these numbers.

• Yesoul G1M Plus: listed 94 x 19 x 61 cm, likely box size
• Wenoker JC318: listed 95 x 19 x 76 cm, likely box size
• Wenoker JC305W: listed 92 x 19 x 76 cm, likely box size
• SEKAM SK-MEB: listed 64 x 17 x 81 cm, likely box size
• VirtuFit Stage 2.0i: listed 132 x 115 x 52 cm, axes look swapped
• Upreign spin bike: listed 89 x 112 x 56 cm, axes look swapped
• StoneGrit LRC-001 recumbent: listed 128 x 80 x 56 cm, height looks too low
• MERACH S08 recumbent: listed 54 x 25 x 116 cm, too small for a recumbent
• BH Osaka H9110: dimensions plausible, but the listed maximum user weight of 32 kg is clearly wrong
• Capital Sports Evo Race and BH SB Mag: no usable dimensions on the listing

Typical sizes by bike type

Folding X-bikes and compact uprights are the shortest. From the listings above they run from about 65 to 100 cm long and 45 to 60 cm wide, and many fold to stand flatter against a wall. They are the natural choice for a small flat. Our small spaces stage covers folding options.

Spin bikes are usually a little longer, around 100 to 110 cm in the listings here, and about 50 cm wide at the base. They are tall at the handlebars and the frame does not fold, so they need a permanent spot. See our best spin bike under 500 guide for compact models.

Recumbents are the longest at roughly 140 cm, and often over 60 cm wide at the seat. A sliding seat rail means the working length can change with the rider. If you want a small recumbent, look at folding bikes with a backrest, which give a reclined seat in a shorter frame.

Ceiling height for tall riders

Ceiling height rarely matters on a recumbent, but it can on a spin bike, because riders often stand on the pedals. At the top of each pedal stroke your foot rises well above the pedal's lowest point, and standing puts your head higher than when you are sitting. Rooms with a low sloping ceiling, a loft or a basement with low beams are the usual problem.

To check, stand on a step of about the same height as the bike's highest pedal position, or simply sit on the bike in the shop or at a friend's home and stand up on the pedals. Leave a clear gap above your head. Also look for light fittings and ceiling fans, which are easy to forget. Check the maximum user height on the listing, which tells you whether the saddle will go high enough for a tall rider in the first place.

Clearance and room for a fan

The listed footprint is only the bike. You also need room to step on and off, to reach the resistance knob and to clean around the frame. Many manuals give a recommended clear zone around the machine; check yours and follow it. Leave enough room at the side you mount from to stand comfortably next to the bike.

A fan makes indoor riding far more pleasant, and it needs space too. A pedestal or floor fan works best in front of the bike, angled at your upper body. Allow room for its base and for the cable to reach a socket without crossing the path you walk on. If your bike has a screen, plan where its power lead runs as well.

1. 1

   Mark the listed length and width on the floor with masking tape.

2. 2

   Add the clear zone from the manual on all sides.

3. 3

   Add space in front for a fan and its cable.

4. 4

   Check headroom above the saddle for the tallest rider.

5. 5

   Check the route from the door, as the box is larger than the bike.

Note:Keep power cables for fans and bike screens out of the way of pedals and feet, and never run them under a mat where they can be damaged.

Compare exercise bikes →

Frequently asked questions

What are typical spin bike dimensions? From the listings in our guides, spin bikes with plausible figures are about 104 to 108 cm long, roughly 50 cm wide and 112 to 116 cm tall at the bars. Always confirm the assembled size in the manual, as some listings give box sizes.

Is there a small recumbent exercise bike? Full recumbents in our guides are around 140 cm long. Folding bikes with a backrest, such as 4-in-1 or 5-in-1 designs, give a reclined seat in under a metre. See our recumbent bike guide.

Which exercise bike is best for small spaces? A folding X-bike or compact upright takes the least floor and can often be stored flatter. Our best exercise bike guide includes folding options.

Why do some listings show a width of under 20 cm? That is almost always the shipping box or a single part, not the assembled bike. Ask the seller or check the manual.
